Description:

Our factory is Shenzhen Xindahui Electronics Co., Ltd. Our company which have an area of about 3960 square meters, specialized in the production:

1)1-28 multi-layer PCB board

2)Aluminum base board

3)Thick copper board

4)FPC board,high frequency board and other special PCB board

1)Technical requirement:

 1.Professional Surface-mounting and Through-hole soldering Technology

 2.Various sizes like precision 0201,0402, 0603, 0805, 1210 and 2512 components SMT technology

 3.ICT(In Circuit Test),FCT(Functional Circuit Test) technology.

 4.PCBA Assembly With CE, Reach, Rohs Approval

 5.Nitrogen gas reflow soldering technology for SMT.

 6.High Standard SMT & Solder Assembly Line

 7.High density interconnected board placement technology capacity.

 2)Quote requirement:

1.Gerber files of the bare PC board

2.BOM file (Components List): manufacturers part number, type of part, packaging type, component locations and quantity

3.Dimensional specification for non-standard components

4.Assembly drawing

5.Final test procedures (if applicable)

6.in order to shorten the lead time, please advise us alternative parts (same specifications but different brand name)

7.Estimated order quantity

8.If possible, please send prototype/sample board/photo to us for further reference

2.We also offer:

1.Contract Manufacturing

2.Engineering Services

3.PCBA Assembly

4.PCBA Copy

6.Prototyping
